Praveen Pandey

Software Engineer

Bengaluru, Karnataka, India13 yrs 1 mo experience
Most Likely To SwitchHighly Stable

Key Highlights

  • Expert in Physical Design and ASIC implementation.
  • Proven track record in managing complex semiconductor projects.
  • Strong background in digital and analog circuit design.
Stackforce AI infers this person is a Semiconductor Design Engineer with expertise in ASIC and Physical Design.

Contact

Skills

Core Skills

Physical DesignAsic Design

Other Skills

IP DesignTiming ClosurePower ManagementSynthesisSignoffPhysical VerificationDigital ImplementationTool SupportDigital DesignsAnalog Circuit DesignDigital Signal ProcessingMicroelectronicsMaterials ScienceSystem Level DesignMemory Design

About

ASIC(Application specific IC) Design SoC(System On Chip) Design Physical Design & Verification

Experience

13 yrs 1 mo
Total Experience
2 yrs 2 mos
Average Tenure
3 yrs 11 mos
Current Experience

Cadence design systems

2 roles

Senior Principal Design Engineer

Promoted

Jun 2024Present · 2 yrs · Bengaluru, Karnataka, India

Principal Design Engineer

Jul 2022Jun 2024 · 1 yr 11 mos · Bengaluru, Karnataka, India

  • IPG R&D group - Physical Design Implementation
  • Interface/Memory IP | SerDes | PCIe | D2D | UCIe | Ethernet | MIPI | USB | Automotive Grade IP's | Testchips (5/3/2 nm)

Qualcomm

2 roles

Staff Engineer (Physical Design)

Nov 2021Jul 2022 · 8 mos

  • physical designing of IP's, Infrastructure tiles, Modem and/or DDR for the Qualcomm premium tier snapdragon platform (7/5/4 nm)
  • Different design complexities included multiple clocks balancing requirements, sub-systems with 6 sub-blocks with 1 million instances each, ~2 million instance designs, 1.2 Ghz frequency , ~5K feedthroughs, 8 voltage domains, primary power switchable designs / power switches enabled , power muxes, analog + digital IP's , custom clock structure , congestion and timing critical designs etc.
Physical DesignIP DesignTiming ClosurePower ManagementASIC Design

Senior Lead Engineer (Physical Design)

Aug 2018Nov 2021 · 3 yrs 3 mos

Smartplay technologies - an aricent company

Senior Physical Design Engineer

May 2017Jun 2018 · 1 yr 1 mo · Noida Area, India

  • Worked on all the aspects of Synthesis, Physical Design and Signoff including Floor Planning, Power Plan, Place and Route,
  • Clock Planning and Clock Tree Synthesis, Parasitic Extraction, Timing Closure, Power / IR Drop (Static), Signal Integrity
  • Analysis, Physical Verification (DRC, ERC, LVS) and DFM.
  • Tools: Genus, Innovus/ Encounter, Spyglass Constraints checker, Tempus, Calibre, Voltus, StarRC
SynthesisPhysical DesignSignoffTiming ClosurePhysical VerificationASIC Design

Mentor graphics

Product Specialist II

Dec 2013May 2017 · 3 yrs 5 mos · Noida Area, India

  • Worked as a part of deployment team to provide technical support for users of Olympus/Nitro-SoC (Mentor Graphics complete digital implementation system for advanced-node ICs and SoCs). Providing custom scripts, design flows and detailed tool diagnostics for digital physical design at advanced nodes (28nm, 16nm, 10nm, 7nm).
  • Specialties: Strong physical design, analysis and debug experience.
  • Responsibilities included:
  • Implementation (PnR) of multimillion gate SoC designs in cutting edge process technologies (28nm, 16nm, 10nm & 7nm) using Nitro-SoC.
  • All aspects of Physical Design including Floor Planning, Power Plan, Integrated Package and Floorplan design, Place and Route, Clock Planning and Clock Tree Synthesis, Parasitic Extraction, Timing Closure, Power / IR Drop (Static and Dynamic), Signal Integrity Analysis, Physical Verification (DRC, ERC, LVS), DFM and DFY.
  • Innovate on the flows to meet the QoR targets and ensure predictability using Nitro-SoC
  • Exposure to the latest design rules, processes and innovations need to close PPA on the advance nodes.
Digital ImplementationPhysical DesignTool SupportASIC Design

Tevatron technologies pvt. ltd.

VLSI Design Intern

Jul 2013Dec 2013 · 5 mos · Noida Area, India

  • “Worked On AMBA & I2C Bus Design and Verification”, “FPGA Implementation” & “Physical Design & Verification”

Electronics corporation of india ltd

Project Trainee

Dec 2012Apr 2013 · 4 mos · Bangaluru

  • Worked on 4 projects from schematic level to layout with Electronics Corporation of India Limited (Government of India Enterprise) under Computer Education Division titled
  • >Physical Design & Analysis of Low Voltage Operational Amplifier
  • >8-bit ADC
  • >Design of Small Signal LNA
  • >RISC based 32-bit general purpose microprocessor in Verilog

Education

Suresh Gyan Vihar University

Master of Technology (Integrated Btech + MTech) — Electronics and Communications Engineering

Jan 2008Jan 2013

St. Joseph's School

SSE — Science

Jan 2007Jan 2008
