May 2022 – May 2023 · 1 yr · Bengaluru, Karnataka, India

Mar 2019 – May 2022 · 3 yrs 2 mos · Bengaluru, Karnataka, India

• Working to Intel as Contingent Worker from Klaus IT Solutions Pvt Ltd
• I will be responsible for the complete layout design activities from Front end to back end (base on ISO design Process) and handling individually up to 20 layers, several BGA’s >2K Pins, 0.4mm, 0.5mm, 0.8mm pitch BGAs with Blind and Buried Via techniques, HDI Micro via - Stacked and Staggered Micro vias & Back drill VIA.
• Major Key projects involved: Blade Server boards, Network boards, mixed signal boards, communications systems – GSM ,LTE, Avionics, Defense boards, Tablet PC boards, Power Electronics boards, EMC/EMI certification of the products, Analog, RF and ATE Platform boards.
• Worked in Interfaces PCIe, Ethernet, DDR, SATA, UART, HDMI, MIPI, USB and QSFP socket interfaces and constraints setting.
• PCB Library database, verification of Sch Symbols & footprint as per IEE, IPC standard surface mount design & land pattern standards & also other components which as per industry standards using Allegro EDA & ADW tools.
• The layout technique for High-speed designs up to 4gpbs as well as EMI, EMC, Cross take, Reflection, Control Impedance skew and Length matching, Mechanical skew Problems, DFM, DFT, DFA and PCB Manufacturing Process considerations during layout work.
• Efficiency of Placement and Density of Routing to all relevant IPC, ITU-T, IEC, and MIL Standard High Frequency Design.
• Have strong understanding of Design requirements and have good interacted with multiple teams – Design, SI, PI, and Mechanical team to execute the projects and Resolve PWB design Issues via Email, Data Management tools(EDM, DS-CR), web meeting and Instant messaging..
• Worked in closely with manufacturers to assure that the product meets the DFM/DFA/DFT requirements.
• Optimized component selection towards new designs based on functional, environmental and compliance requirements - as needed throughout the product life cycle.

Jan 2018 – Mar 2019 · 1 yr 2 mos · Bengaluru, Karnataka, India

• Responsible for PCB CAD/CAM Design activities which includes below
• Customer Input Validation.
• Schematic HDL capturing, Net list and Bill of material generation.
• Check list and Database creation.
• Library Management Data, Schematic Symbols and PCB Footprint Creation.
• Design Constraint Requirement, Board creation.
• Placement, Routing, Finishing Touches and DRC-Design rule check.
• Gerber, Drill generating, Stencil, PnP, Array Drawings, Fabrication Documents and verifying PCB layout rules.
• DFM Validation with Check list & creating manufacturing specification for PCB Vendors.
• Preparing Final Folder and customer Deliverables.

Oct 2015 – Dec 2017 · 2 yrs 2 mos · Chennai, Tamil Nadu, India

Mar 2014 – Aug 2015 · 1 yr 5 mos · Bengaluru, Karnataka, India
