chethan s

Product Engineer

Bengaluru, Karnataka, India14 yrs 5 mos experience
Most Likely To SwitchHighly Stable

Key Highlights

  • Expert in GLS methodology for simulation optimization.
  • Proficient in VT environment setup for processor testing.
  • Strong background in semiconductor product testing.
Stackforce AI infers this person is a Semiconductor Test Engineering expert with a focus on VLSI and GLS methodologies.

Contact

Skills

Core Skills

Test EngineeringVlsiGls

Other Skills

DFTASICSemiconductorsSoCCharacterizationDebuggingICProduct EngineeringTestingC++VHDLVerilogCVerigy 93KVT

About

Working as Senior Engineer in Qualcomm India Pvt Ltd. Responsible for the Vectors generation & support across projects, implementation of GLS methodology to reduce simulation time & vector memory. GLS simulations on peripherals & Provide necessary solution to root cause & solve the silicon issues on functional & characterization platform on ATE. Virtual test bench (VT) environment bring up & VT simulations along with binary/vector environment setup which will be used for binary generation for testing the processor (chip). wafer & package testing support across MDM/MSM chips •Skills: 1. GLS simulations qualifications for MDM/MSM chips 2. VT (virtual test bench) environment bring up & VT simulations for RTL & GLS based tests 3. Binary generation with optimal methods to reduce test time & vector memory 4. Implementation of new methodology for low speed peripherals to reduce bring up qualification time 5. Silicon debug at wafer and package level, Test and Production program development and Test Time Reduction. 6. AC characterization parameters measurement like setup time, hold time, propagation delay and data valid time measurement. 7. Worked on peripherals interfaces like SLIMBUS, JTAG, I2C, I2S, HSIC, SPI, SPMI, LCDC, TSIF, RFFE and SDCC. 8. Implementation of new methodology in GLS simulations to reduce overall simulation time & memory usage. Role: •Interact and co-ordinate with Design and DFT Engineers in on-site and off-shore to understand and resolve/debug device functional/characterization issues. •Remote test debug using testers in US and Singapore. •Conversion from different test languages (VCD, EVCD, STIL) to ATE format. •Developed and implemented test plans on ATE from device specifications. •Worked with the Product Engineering group to enhance production yield and reduce cost. •Verified devices Process, Temperature and Voltage corners. (27 corner testing) . Specialties: VERIGY 93K Test Platform.

Experience

14 yrs 5 mos
Total Experience
3 yrs 7 mos
Average Tenure
7 yrs
Current Experience

Intel corporation

Product Development Engineer

Jun 2019Present · 7 yrs · Bangalore Urban, Karnataka, India

VLSITest EngineeringDFTASICSemiconductorsSoC+14

Qualcomm

Senior Engineer

Jan 2016Jun 2019 · 3 yrs 5 mos · Bangalore india

  • Working as Senior Engineer in Qualcomm India Pvt Ltd. Responsible for the Vectors generation & support across projects, implementation of GLS methodology to reduce simulation time & vector memory. GLS simulations on peripherals & Provide necessary solution to root cause & solve the silicon issues on functional & characterization platform on ATE. Virtual test bench (VT) environment bring up & VT simulations along with binary/vector environment setup which be used for binary generation for testing the processor (chip). wafer & package testing support across MDM/MSM chips
GLS simulations qualifications for MDM/MSM chipsVT environment bring up & VT simulationsBinary generation with optimal methodsImplementation of new methodology for low speed peripheralsSilicon debug at wafer and package levelAC characterization parameters measurement+3

Anora semiconductor pvt ltd

Product Development Engineer

May 2015Dec 2015 · 7 mos · Bangaon Area, India

  • Working as PDE in Anora Semiconductor Labs Pvt Ltd. Responsible for Test programs development on Advantest (Verigy) 93K ATE platform for SOC (system on chip) devices. The role even includes test time reduction and test program optimization. ROLE: • Test program development for various digital tests on 93k platform. • Load board schematic verification and review for automotive and SOC products. • Overall product test program verification at different corners. • Pattern conversion for 93k tester platform. • Test Program verification and correlation with different tester platform. • Final test program audit and quality check (QA/QC) verification on 93k (Verigy) platform. • Spike testing and analysis.
Test programs development on Advantest 93K ATE platformTest time reduction and optimizationLoad board schematic verificationPattern conversion for 93k tester platformTest Engineering

Tessolve services pvt. ltd.

Post Silicon Validation Engineer

Nov 2011Apr 2015 · 3 yrs 5 mos · Singapore

  • Working as VLSI Test Engineer in Tessolve and client place, Qualcomm Singapore since a year and half as a Digital Engineer, responsible for developing AC characterization Test programs on Advantest (Verigy) 93K ATE platform for MSM (Mobile Station Modem), MDM (Mobile Data Modem) and SIP (System In Package) devices as Test Program Optimization involving yield enhancement and test time reduction. Understanding of the entire Semiconductor Product Testing life cycle.
AC characterization Test programs developmentTest Program OptimizationUnderstanding of Semiconductor Product Testing life cycleTest Engineering

Education

city engineering college

Engineer's Degree — electronics and communication

Jan 2007Jan 2011
